busbar application in power grid

busbar application in power grid

the proven quality of our products is based on internationally leading design and manufacturing concepts, combined with state-of-the-art production equipment. our talented engineers have many years of experience in producing busbars.whether our customers wish to develop a completely new solution, optimize a design or just produce their existing design under optimized conditions, we are your dedicated partner for laminated busbars.



project: yu-e hvdc light ±500kv laminated busbar

parameter:

voltage: 2200v dc

current: 1250a

dielectric strength: 5.0 kv -ac-60s, no breakdown, no flicker.( leakage current ≤ 2ma)

partial discharge:<5pc @ 2000v ac


project: “zhoushan” dc breaker ±200kv laminated busbar-274

parameter:

voltage: 4500v dc

current: 200a

dielectric strength: 10kv -dc-60s, no breakdown, no flicker.

partial discharge: ≤10pc @ 3600v ac

project: “xiamen” hvdc light ±320kv laminated busbars

parameters:

voltage:2000v

current: 500a

project: zhangbei hvdc light ±500kv laminated busbar

parameter:

voltage : 2000v

current: 800a

dielectric strength: 7.0 kv -ac-60s, no breakdown, no flicker.

( leakage current ≤ 3ma)

partial discharge: ≤10pc @ 1200v ac
